Wheeled Backhoe Loader MR30-25

Price:

$18,000-$18,600 / EA

1 Unit / EA (Min. Order)

Payment Terms:

Delivery time: 7-15 Days

Shipping: Container Flat Rack Roro

Inquire Now Next Product

Product Description

MR30-25 Backhoe Loader
The backhoe loaders are mainly used for municipal, building, water conservancy, road, water, electricity, garden and other departments, engaged in agricultural construction, pipe laying, cable laying, landscaping and other jobs.
1). Domestic famous engine, strong driving force, low fuel consumption.
2). Power shift transmission with hydraulic torque converter, delivers smooth speed and shift.
3). Heavy axle and four wheel driving improves mobility in poor condition.

MR30-25 Heavy Backhoe Loader

1). Full hydraulic transmission. Adjust the output torque automatically according to loads change, and it can achieve continuously variable transmission. It enables the machine working efficient and easy to maintenance.

2). High productivity. Super lifting force and automatic leveling at high position.
3). Operation flexible. Center-point frame articulated and small turning radius makes it convenient to work in confined places.
4). Safe and reliable. Single-line air-assisted brake system.


Wheeled Backhoe Loader MR30-25

Specification

overall dimension	7820x2300x3180mm
operate weight	7100kg
wheelbase	2550mm
min.ground clearance	350mm
bucket capacity	1.0m3
breakout force	38kN
loading lifting capacity	2500kg
bucket dumping height	3320mm
bucket dumping distance	1100mm
bucket raising height	4770mm
backhoe capacity	0.3m3
max.digging depth	4640mm
sing angle of excavator grab	190°
max.pulling force	39kN
Engine
Model	YUCHAI
Rated Power	85kw
Pattern	Straight, Direct Injection, Four-stroke, Direct-spraying Combustion Chambe
Cylinder Number-Inner Diameter-Stroke	4-108×120
Rated Rotational Speed	1800r/min
Min. Fuel Consumption	≤216g/km.h
Max. Torque	≥261.7N.M/1800r/min
Displacement	4.4L
Transmisson System
torque converter	YJ280 single-stage three elements
gearbox	fixed shaft power transmission
gears	F2/R2
max. speed	22km/h
Steering System
model	BZZ5-250
steering angle	±36°
min. turning radius	5018mm
system pressure	16Mpa
Axle
manufacturer	YUNYU
main drive type	double reduction
final reducer	single stage final reducer
Braking System
parking brake	manual disc brake
Service Brake	air-over-oil caliper disc brake, external, self-regulation, self-balance
Tyre
size	16/70-24
Hydraulic System
digging power of excavator grab	46.5KN
digging power of dipper	31KN
