Price:
$15,000-$19,000 / EA
1 Unit / EA (Min. Order)
Product Description
We are top and professional semi-trailer supplier.
We can give you better products at favorable price.
Advantage:
1. Many types are optional
2. More than 13 years professional manufacturer experience
3. Will design according to your requirements
4. CCC ISO9001 SGS WMI agreement
5. Small order can be accepted
6. 1 year quality guarantee
7. We accept 100% inspection, welcome to our factory at any time you need
Features:
1. Our bulk cement tank trailer adopts high strength wear-resistant steel.
Especially for African market, considering the road condition. Its distortion resistance, earthquake resistance and bump, make your transport safety , beneficial, more durable and more sturdy, it can ensure the tank very firm.
2. It adopts the latest advanced automatic splice plate machine to weld the steel plate with double-side to ensure the high quality of welding seams, long service life and good appearance in tank body,long service life
3. After the production, our trailers will go through the pressure test and metal inspection testing to ensure a good sealing property.
Specification
Trailer Model | 40m3 BULK CEMENT SEMI TRAILER |
Overall Dimension( LxW xH)(mm) | 10700x2500x3950mm |
Function | transport bulk powder |
Loading Weight( KG) | 54000 |
Thickness(mm) | Tank body: Q235 5mm carbon steelEnd plate: Q235 5mm carbon steel |
Air compressor | 12m3/minute Bohai brand |
Engine | Diesel engine: Weichai Tianhe 4102 |
Compartment | 1 inner fluidized bed: air bag |
Axle | 3 x13Ton, ZY brand |
Suspension system | Mechanical leaf spring suspension |
Leaf spring | 90(W)mm*13(Thick)mm*10 Layer |
Manhole cover | 500mm manhole cover. 2 sets |
Landing Gear | 28Ton, double speed, Yahua brand |
Tire | 12R22.5, Taitong brand 12units |
Traction Pin | 2" or 3.5" bolts in, changeable |
Spare Wheel Bracket | 2 pieces |
Tool Box | 1 Standard |
Side guard | According to customer's requirement |
Brake system | Dual Line braking system |
Emergency valve | WABCO |
Brake air chamber | Six big double air chambers |
Electrical system | 1. Voltage: 24v 2. Receptacle: 7 ways (7 wire harness) |
Tail lamp with turn signal, brake light & reflector, side lamp etc. | |
One set 6-core standard Cable. | |
Painting | Shot blast at Standard SA 2.5 prior to application of primer, polyurethane top coat. Total DFT not less than 100um,A layer of anti-rust paint,two-layer finish. |
Packing | Polish with wax before shipping |
