Product Description

XS163H Full Hydraulic Single Drive Vibratory Roller

The XS163H fully hydraulic single-drive vibratory roller is more comfortable to operate and offers superior compaction performance and efficiency.

It is suitable for compaction operations such as concrete, stabilized soil, pebbles, sandy soil, and sticky soil.

It is an ideal compaction device for the construction of high-grade highways, airports, ports, and embankments.


Specification

Description	Unit		Parameter value
Work weight	kg		16000
Drive wheel distribution weight	kg		8000
Vibratory drum distribution weight	kg		8000
Static line load	N/cm		362
Vibration frequency	Hz		28/33
Theoretical amplitude	mm		1.8/0.9
Exciting force	kN		290/200
Speed range	km/h		0-7.3
Wheelbase	mm		3040
Compaction width	mm		2130
Theoretical climbing ability	%		30
Minimum turning radius	mm		6800
Vibratory drum diameter	mm		1523
Minimum ground clearance	mm		431
Engine	Model		SC7H150G2
	Rated speed	r/min	2200
	Rated power	kW	110
Dimensions	mm		6150×2300×3200
Vibration system pressure	MPa		18
Steering System Pressure	MPa		16
