Price:
$65,000-$75,000 / EA
1 Unit / EA (Min. Order)
Product Description
1. Powerful engine conforming to Stage II emission regulations
2. Advanced power shift (6F/3R) transmission
3. Reliable and durable three-section axle with limited slip differential
4. Comfortable cab located on front frame provides great visibility and easy operation
5. World class variable piston pump divides flow efficiently for lower power consumption
6. Proportional, pressure compensating hydraulics provide smooth operation with increased efficiency
7. Electro-Hydraulic control center-shift pin and blade linkage provide world-class blade reach and fast positioning
8. Optimized blade curvature and throat clearance for increased productivity
9. Unique front axle design provides optimum wheel lean and machine mobility
10. Wide range of attachments to meet customer-specific job requirements
Specification
| Items | SEM919 |
| Operation Weight (Base Machine) | 15,070kg |
| Overall Dimensions (L*W*H) | 8,703*2,630*3,360mm |
| Blade Length (L*W*H) | 3,974*25*607mm |
| Max. Lifting Height | 475mm |
| Max. Depth of Cut | 715mm |
| Max. Drawbar | ≥78kN |
| Wheelbase | 6,140mm |
| Frame Articulation Angle | 20° |
| Min. Turning Radius | 7.8m |
| Engine Brand | SDEC SC9DK190.1G3 |
| Rated power | 140kW |
| Transmission Type | Hangchi 6WG180 |
| Travel Speed (Forward/Rear) | 40/25km/h |
| Rear Axle/Tandem | SEM ST22 |
| Service brake | Outboard disc with brake caliper,Air to oil Control |
| Oscillation (Front up/Rear up) | 15/25° |
| Max. Oscillation Angle | ±16° |
| Steering Angle (Left/Right) | 47.5° |
| Max. Lean Angle of Front Wheels | 18° |
| Hydraulic System | Load sensing,PPPC |
